Known as third generation of Rare Earth magnets, Neodymium Iron Boron (NdFeB) magnets are the most powerful and advanced commercialized permanent magnet today. Since they are made from Neodymium, one of the most plentiful rare earth elements, and inexpensive iron, NdFeB magnets offer the best value in cost and performance.
NdFeB magnets are available in both sintered and bonded forms. Sintered NdFeB offers the highest magnetic properties (28 MGOe to 50 MGOe) while Bonded NdFeB offers lower energy properties. Although bonded magnets do not possess magnetic properties as advanced as those of sintered magnets, they can be made in shapes and sizes that are difficult to achieve with sintering.
A variety of coatings can be applied to the magnets' surface to overcome the principle drawback of neodymium-based magnets, their tendency to corrode easily.
 |
Sintered
NdFeB Magnets
|
 |
| Adobe Acrobat Reader |
Typical Magnetic Properties
|
Grade |
Max. Energy Product |
Remanence |
Coercive Force |
Rev. Temp. Coeff. |
Curie Temp. |
Max. Working Temp.
|
||||||
|
(BH)max |
Br |
Hc |
Hci |
Bd |
Hd |
Tc |
Tw |
|||||
| MGOe |
kJ/m3 |
kG |
mT |
kOe |
kA/m |
kOe |
kA/m |
%/°C |
%/°C |
°C |
°C |
|
|
N27 |
25-29 |
199-231 |
10.50 |
1050 |
>10.0 |
>796 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N30 |
28-31 |
223-247 |
11.00 |
1100 |
>10.2 |
>812 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N33 |
31-33 |
247-263 |
11.50 |
1150 |
>10.5 |
>836 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N35 |
33-36 |
263-287 |
12.00 |
1200 |
>10.9 |
>868 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N38 |
36-39 |
287-310 |
12.40 |
1240 |
>11.3 |
>899 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N40 |
38-41 |
302-326 |
12.70 |
1270 |
>11.4 |
>907 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N42 |
40-43 |
318-342 |
13.00 |
1300 |
>11.5 |
>915 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N45 |
43-46 |
342-366 |
13.50 |
1350 |
>11.6 |
>923 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N48 |
46-49 |
366-390 |
14.00 |
1400 |
>11.6 |
>923 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N50 |
48-51 |
382-406 |
14.30 |
1430 |
>10.3 |
>820 |
>12.0 |
>955 |
-0.12 |
-0.60 |
310 |
80 |
|
N52 |
50-53 |
398-422 |
14.50 |
1450 |
>10.3 |
>820 |
>11.0 |
>877 |
-0.12 |
-0.60 |
310 |
80 |
|
N30M |
28-31 |
223-247 |
11.00 |
1100 |
>10.2 |
>812 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N33M |
31-33 |
247-263 |
11.50 |
1150 |
>10.5 |
>836 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N35M |
33-36 |
263-287 |
12.00 |
1200 |
>10.9 |
>868 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N38M |
36-39 |
287-310 |
12.40 |
1240 |
>11.4 |
>907 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N40M |
38-41 |
302-326 |
12.70 |
1270 |
>11.6 |
>923 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N42M |
40-43 |
318-342 |
13.00 |
1300 |
>12.0 |
>955 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N45M |
43-46 |
342-366 |
13.50 |
1350 |
>12.5 |
>995 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N48M |
46-49 |
366-390 |
14.00 |
1400 |
>12.9 |
>1027 |
>14.0 |
>1114 |
-0.12 |
-0.59 |
320 |
100 |
|
N50M |
48-51 |
382-406 |
14.30 |
1430 |
>13.1 |
>1043 |
>14.0 |
>1114 |
-0.11 |
-0.58 |
320-350 |
100 |
|
N30H |
28-31 |
223-247 |
11.00 |
1100 |
>10.2 |
>812 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N33H |
31-34 |
247-271 |
11.50 |
1150 |
>10.5 |
>836 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N35H |
33-36 |
263-287 |
12.00 |
1200 |
>10.9 |
>868 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N38H |
36-39 |
287-310 |
12.40 |
1240 |
>11.4 |
>907 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N40H |
38-41 |
302-326 |
12.70 |
1270 |
>11.6 |
>923 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N42H |
40-43 |
318-342 |
13.00 |
1300 |
>12.0 |
>955 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N45H |
43-46 |
342-366 |
13.50 |
1350 |
>12.5 |
>999 |
>17.0 |
>1353 |
-0.11 |
-0.58 |
320-350 |
120 |
|
N48H |
46-49 |
366-390 |
14.00 |
1400 |
>12.9 |
>1027 |
>17.0 |
>1353 |
-0.11 |
-0.55 |
340-360 |
120 |
|
N30SH |
28-31 |
223-247 |
11.00 |
1100 |
>10.2 |
>812 |
>20.0 |
>1592 |
-0.11 |
-0.55 |
340-360 |
150 |
|
N33SH |
31-34 |
247-271 |
11.50 |
1150 |
>10.6 |
>844 |
>20.0 |
>1592 |
-0.11 |
-0.55 |
340-360 |
150 |
|
N35SH |
33-36 |
263-287 |
12.00 |
1200 |
>11.0 |
>876 |
>20.0 |
>1592 |
-0.11 |
-0.55 |
340-360 |
150 |
|
N38SH |
36-39 |
287-310 |
12.40 |
1240 |
>11.4 |
>907 |
>20.0 |
>1592 |
-0.11 |
-0.55 |
340-360 |
150 |
|
N40SH |
38-41 |
302-326 |
12.70 |
1270 |
>11.8 |
>939 |
>20.0 |
>1592 |
-0.11 |
-0.55 |
340-360 |
150 |
|
N42SH |
40-43 |
318-342 |
13.00 |
1300 |
>12.4 |
>987 |
>20.0 |
>1592 |
-0.11 |
-0.55 |
340-360 |
150 |
|
N45SH |
43-46 |
342-366 |
13.50 |
1350 |
>12.6 |
>1003 |
>20.0 |
>1592 |
-0.11 |
-0.51 |
350-380 |
150 |
|
N28UH |
26-29 |
207-231 |
10.60 |
1060 |
>9.6 |
>764 |
>25.0 |
>1990 |
-0.11 |
-0.51 |
350-380 |
180 |
|
N30UH |
28-31 |
223-247 |
11.00 |
1100 |
>10.2 |
>812 |
>25.0 |
>1990 |
-0.11 |
-0.51 |
350-380 |
180 |
|
N33UH |
31-34 |
247-271 |
11.50 |
1150 |
>10.8 |
>860 |
>25.0 |
>1990 |
-0.11 |
-0.51 |
350-380 |
180 |
|
N35UH |
33-36 |
263-287 |
12.00 |
1200 |
>11.3 |
>899 |
>25.0 |
>1990 |
-0.11 |
-0.51 |
350-380 |
180 |
|
N38UH |
36-39 |
287-310 |
12.40 |
1240 |
>11.5 |
>915 |
>25.0 |
>1990 |
-0.11 |
-0.51 |
350-380 |
180 |
|
N40UH |
38-41 |
302-326 |
12.70 |
1270 |
>11.8 |
>939 |
>25.0 |
>1990 |
-0.11 |
-0.51 |
350-380 |
180 |
|
N28EH |
26-29 |
207-231 |
10.70 |
1070 |
>9.8 |
>780 |
>30.0 |
>2388 |
-0.11 |
-0.51 |
350-380 |
200 |
|
N30EH |
28-31 |
223-247 |
11.10 |
1110 |
>10.2 |
>812 |
>30.0 |
>2388 |
-0.11 |
-0.51 |
350-380 |
200 |
|
N33EH |
31-34 |
227-271 |
11.50 |
1150 |
>10.8 |
>860 |
>30.0 |
>2388 |
-0.11 |
-0.51 |
350-380 |
200 |
|
N35EH |
33-36 |
263-287 |
12.00 |
1200 |
>11.1 |
>884 |
>30.0 |
>2388 |
-0.11 |
-0.51 |
350-380 |
200 |
|
N38EH |
36-39 |
287-310 |
12.40 |
1240 |
>11.5 |
>915 |
>30.0 |
>2388 |
-0.11 |
-0.51 |
350-380 |
200 |
|
N28AH |
26-29 |
207-231 |
10.70 |
1070 |
>9.8 |
>780 |
>35.0 |
>2786 |
-0.11 |
-0.51 |
350-380 |
220 |
|
N30AZ |
28-31 |
223-247 |
11.10 |
1110 |
>10.2 |
>812 |
>35.0 |
>2786 |
-0.11 |
-0.51 |
350-380 |
220 |
|
N33AH |
31-34 |
227-271 |
11.50 |
1150 |
>10.8 |
>860 |
>35.0 |
>2786 |
-0.11 |
-0.51 |
350-380 |
220 |
|
N35AH |
33-36 |
263-287 |
12.00 |
1200 |
>11.1 |
>884 |
>35.0 |
>2786 |
-0.11 |
-0.51 |
350-380 |
220 |
ISO 9001:2008 Quality Standard Certified
Physical and Mechanical Properties
| Thermal Conductivity |
7.7 kcal/m-h-°C |
Electrical Resistivity |
160 µ-ohm-cm/cm2 |
| Young�s Modulus |
1.7 x 104 kg/mm2 |
Density |
7.4-7.5 g/cm3 |
| Bending Strength |
24 kg/mm2 |
Vickers Hardness |
500 - 600 |
| Compressive Strength |
80 kg/mm2 |
